KEY FEATURES

hot water room heating

Hot Water Room Heating & Cooling:

Hot Water Room Heating & Cooling.

hp-mn-hp-reliable-compressor

Reliable Compressor:

Rugged and reliable Scroll compressor with high efficiency heat exchanger - reliable and durable.


hp-high-low-pressure

High & Low Pressure Switch Protection:

hp-expansion-valve

Expansion valve:

The expansion valve is an important component in the Heat pump water heater operation.

hp-nm-hp-controller

Intelligent Electronic Controller:

Intelligent automatic LCD controller to set temperature and time options.

hp-nm-hp-high-energy4.2

High Energy Efficiency - COP of 4.2:

Utilizes as low as 0.83 / 1.19 / 1.79 kW input; delivers heat output up to 3.5 / 5.0 / 7.5 kW COP of 4.2

Split system for flexible installation

Split System for flexible installation:

It consists of external and internal units for installation.

hp-mn-hp-water-circulation-Multfunction

Water circulation technology:

Safe and reliable water circulation technology that ensures no mixing of refrigerant and water.

Low operating cost - more savings

Low operating cost - more savings:

More savings as the operating costs are low.

hp-nm-ac-remote

Operating at lower or higher temperature

hp-nm-hp-circulation-pump

Circulation Pump:

Specification

Parameters \ Model VMFHP7.5
Hot Water Rated hot water capacity/td> L/H 215
Rated power input kW 2.38
COP W/W 4.2
Rated output water temp. °C 55
Maximum output water temp. °C 60
Water pipe(lnlet/Outlet) mm DN25
Cooling capacity
Cooling Capacity kW 7.50
Cooling power input kW 2.46
EER W/W 3.05
Heating Capacity
Heating Capacity kW 8.50
Heating power input kW 2.70
COP W/W 3.15
Working ambient temp. °C (-) 7-45
Power supply V/Ph/Hz 220/1/50-60
Compressor Type Rotary
Refrigerant Type R407C
Dimension
Length mm 715
Width mm 715
Height mm 830
Unit noise level dB(A) 51
Net / Gross weight kg 90/95

Note: 1. Rated cooling conditions: Ambient temperature DB35°C, water temperature: inleVoutlet: 12°C/7°C
2. Rated heating conditions: Ambient temperature DBTC, water temperature: inleVoutlet: 40°C/45°C
3. Rated hot water: Ambient temperature DB20°C, water temperature: 15°C-55°C
* Specifications subject to change without prior notice
