Key Features

8 bar

8 Bars Pressure:

Suitable for pressure pumps and multi - storey buildings.

abs-plastic-lids

ABS Plastic Lids:

Manufactured in a modern, automated plant using European Technology. Protects the tank from rust and corrosion.

disc-cutout

Disc Cutout:

Reduces heat losses and keeps water hot for much longer.

slim-special-feature

Slim Design With 12” Diameter:

It can be easily concealed inside a false ceiling or fitted in the smallest space.

capillary-thermal-cutout

Capillary Thermostat:

Backup safety device. Cuts off power at 95°C. Prevents overheating.

Magnisium anode

Sacrificial Magnesium Anode:

A Special device to enhance the corrosion protection of the tank by means of "Cathode Action"

Porcelain Enamel Tanks

Porcelain Enameling - by Powder Enamel is the latest technology from Europe and brought to India for the first time by Venus. Porcelain Enamel is a glass - like coating which is fused at 830°C to create a mechanical bond with the metal substrate. This makes the vitreous enamel layer robust and insert, protecting and underlying steel from rust and corrosion.

Scaleguard

Buyers Network

export-map

Specification

Model :

Capacity :

Rated Power (W):

Rated Pressure:

Rated Voltage(V / Hz):

Time required to raise temp. (at 50°C (h:min)):

Gross / Net Weight: (kg + 8%)

Mount:

IP Rating:


Dimensions (in mm) :
A
B
C

15VS

15

1200

8

230 / 50

0:48min

13.5/11.5

Vertical

IPX4

305

475

305

30VS

30

1200

8

230/50

0:48min

17.1/14.6

Vertical

IPX4

305

644

305

50VS

50

1200

8

230 / 50

0:48min

42/32.3

Vertical

IPX4

305

1131

305

* Specifications subject to change without prior notice

export-vertical-slim-series-diagram
