Key Features

tankless 3 phase

3 Phase Model :

12kw, 15kw,18kw & 24kw.

nm6

Leakage Protection:

If the unit detects electricity leakage, the electricity will be cut off by the leakage protector..

tankless over heat

Over heat Protection:

Super safe as it prevents the heat exchanger from over heating (i.e. more than 90°C).

q153-nemonic

Multi Point Usage:

Designed for high usage and supply to multiple points - shower, kitchen, bath etc.

tankless fleximount

Flexi Mount:

It can be fixed inside loft or above false ceilings and can be fixed Vertically or Horizontally, according to the space available..

tankless micro

Microprocessor Control::

System adjusts heating power output to maintain the set temperature even when the water flow rate is altered..

tankless digital temp

Digital Temperature Display:

The set and actual temperature are prominently displayed..

tankless wide pressure

Wide Pressure Range:

Enjoy a better shower as it works both in low and high pressure conditions..

nm3

Flow based operation:

Avoids dry heating as it senses the water flow and switches ON the heating element and switches OFF when there is no water flow.

tankless high temp

6 Bars Pressure:

High Working pressure suitable for connection to pressure pumps

tankless abs outer

ABS Plastic Outer Body :

Compact. Corrosion free. Shock proof.

tankless heat exchanger

Unique Heat Exchanger Technology :

The heating element and water pipe are molded together for quick transfer of heat from element to the water without contact. This ensures quick heating, long life and safety..

Specification

Model :

Wattage(W) :

Rated Voltage :

Wiring Size :

WRequired Rating of Circuit Breaker :

Rated pressure :

Safety class:

Temp.Setting range :

Rate of flow:


Temperature Rise @ :

Dimensions (mm):

Q123

12000 W

400 V, 50 / 60Hz 3Phase, AC

3 x 1.5 mm2

20 amps

0.02 ˜ 0.6Mpa

IP25

30°C - 60°C

1.8 - 12 L/min

7 L/min - 25°C

10 L/min - 17°C

12 L/min - 14°C

A x B x C 385 x 260 x 90

Q153

15000 W

400 V, 50 / 60Hz 3Phase, AC

4 x 2.5 mm2/p>

25 amps

0.02 ˜ 0.6Mpa

IP25

30°C - 60°C

1.8 - 12 L/min

7 L/min - 31°C

10 L/min - 21°C

12 L/min - 18°C

A x B x C 385 x 260 x 90

Q183

18000W

400 V, 50/60Hz 3Phase, AC

4 x 4 mm²

32 amps

0.02 ˜ 0.6Mpa

IP25

30°C - 60°C

1.8 - 12 L/min

7 L/min - 37°C

10 L/min - 26°C

12 L/min - 21°C

A x B x C 385 x 260 x 90

Q243

24000 W

400 V, 50 / 60Hz 3Phase, AC

4 x 6 mm2

40 amps

0.02 ˜ 0.6Mpa

IP25

30°C - 60°C

1.8 - 12 L/min

7 L/min - 49°C

10 L/min - 34°C

12 L/min - 29°C

A x B x C 385 x 260 x 90

* Specifications subject to change without prior notice
