Key Features

Procelain

Porcelain Enamel Glass Lined Tank:

Manufactured in a modern, automated plant using European Technology. Protects the tank from rust and corrosion.

Magnisium anode

Sacrificial Magnesium Anode:

A Special device to enhance the corrosion protection of the tank by means of "Cathode Action"

lvx-threaded-copper

Threaded Copper Element:

High quality copper element ensures long lasting performance.

capillary-thermal-cutout

Capillary Thermal Cutout:

Backup safety device. Cuts off power at 95°C. Prevents overheating.

puf-Nemonic

PUF Insulation:

Reduces heat losses and keeps water hot for much longer.

8 bar

8 Bars Pressure:

Suitable for pressure pumps and multi - storey buildings.

Porcelain Enamel Tanks

Porcelain Enameling - by Powder Enamel is the latest technology from Europe and brought to India for the first time by Venus. Porcelain Enamel is a glass - like coating which is fused at 830°C to create a mechanical bond with the metal substrate. This makes the vitreous enamel layer robust and insert, protecting and underlying steel from rust and corrosion.

Scaleguard

Buyers Network

export-map

Specification

Model :

Capacity :

Rated Power (W):

Rated Pressure:

Rated Voltage(V / Hz):

Time required to raise temp. (at 50°C (h:min)):

Gross / Net Weight: (kg + 8%)

Mount:

IP Rating:

ERP (Class):


Dimensions (in mm) :
A
B
C

50LVX

50

2000

8

230 / 50

1:33min

22.0/19.2

Vertical

IPX4

-

441

560

441

80LVX

80

2000

8

230/50

2:30min

29.4/26.2

Vertical

IPX4

F

441

810

441

100LVX

100

2000

8

230 / 50

3:04min

34.0/30.4

Vertical

IPX4

F

441

950

441

Other Sizes Available (150 Ltr)

* Specifications subject to change without prior notice
