Key Features

puf-Nemonic

PUF Insulation:

Reduces heat losses and keeps water hot for much longer.

heat-retention-technology

Heat Retention Technology:

No Thermal Bridge between the Tank and the external Housing, there by enabling 16 % lower Thermal Losses.

temperature-diplay-nemonic

Temperature Display:

The display indicates the real-time display of the current temperature.

8 bar

8 Bars Pressure:

Suitable for pressure pumps and multi - storey buildings.

Magnisium anode

Sacrificial Magnesium Anode:

A Special device to enhance the corrosion protection of the tank by means of "Cathode Action"

max-safety

Max Safety:

Advanced features that offer Maximum safety and comply with international safety standards.

Porcelain Enamel Tanks

Porcelain Enameling - by Powder Enamel is the latest technology from Europe and brought to India for the first time by Venus. Porcelain Enamel is a glass - like coating which is fused at 830°C to create a mechanical bond with the metal substrate. This makes the vitreous enamel layer robust and insert, protecting and underlying steel from rust and corrosion.

Scaleguard

Buyers Network

export-map

Specification

Model :

Capacity :

Rated Power (W):

Rated Pressure:

Rated Voltage(V / Hz):

Time required to raise temp. (at 50°C (h:min)):

Gross / Net Weight: (kg + 8%)

Mount:

IP Rating:

ERP (Class):


Dimensions (in mm) :
A
B
C

10CVX

10

1200

8

230 / 50

1:33min

9.6/8.5

Vertical

IPX4

C

321

395

321

15CVX

15

1200

8

230/50

0:48min

13.5/11.13

Vertical

IPX4

C

322

505

322

30CVX

30

1200

8

230 / 50

1:30min

20.76/18.23

Vertical

IPX4

C

372

580

372

50CVX

50

1200

8

230 / 50

2:02min

22.00/13.2

Vertical

IPX4

C

371

900

371

* Specifications subject to change without prior notice
